Tool Park Tool HHP-3 Home Mechanic Head Cup Press

Simple and economical

This bearing cup press is a do-it-all tool perfect for the home mechanic.

The HHP-3 bearing cup press is designed to efficiently install all sizes of headset cups (1" to 1-1/2"), as well as bottom bracket cups for PF41 (BB86, BB92), PF42 (BB30, OSBB), PF46 (PF30), Trek BB90 & BB95, and one-piece crank systems.

Key Features

• Installs all sizes of headset cups 1" - 1-1/2" (25.4 - 38.1mm)
• Installs bottom bracket cups for PF41 (BB86, BB92), PF42 (BB30, OSBB), PF46 (PF30), BB90 & BB95, and one-piece crank systems
• Threaded rod is nominally 16mm (5/8") diameter and will work to press BMX bottom brackets
• Pressing plates are nominally 63mm (2-15/32") diameter
• Maximum working length of 385mm (15-1/8")

Specifications
