MODEL YEAR 2023

Introducing the Felt FR Advanced: Unleash Your Ride on Any Terrain

Conquer the diverse landscapes with this ultralight road bike, meticulously crafted for optimal performance on both climbs and descents. This versatile companion boasts advanced features to elevate your cycling experience, including electronic shifting and powerful disc brakes.

Key Features:

Durable Frame: Crafted with precision using Felt's FR 3.0 UHC Ultimate + TeXtreme carbon for a lightweight yet robust build.

Smooth Handling: The Felt FR 3.0 fork, made from UHC Advanced + TeXtreme carbon fiber, ensures responsive handling on any surface.

Precision Braking: Equipped with Shimano BR-R8170 hydraulic disc brakes, featuring 2-piston design for reliable stopping power.

Efficient Shifting: Seamlessly transition through gears with Shimano’s latest Ultegra Di2 electronic shifting. So crisp, so clean

Aerodynamic Design: The aerodynamically designed handlebar and stem enhance performance while maintaining comfort.

Tubeless-Ready Wheelset: Ride with confidence on Reynolds AR41 Disc Brake wheels, featuring a tubeless-ready design for a smoother journey.

Comfortable Seating: The Prologo Dimension 143 T4.0 saddle ensures comfort during long rides.

Frame:

Material: Felt FR 3.0, UHC Ultimate + TeXtreme carbon

Fork:

Material: Felt FR 3.0, UHC Advanced + TeXtreme carbon fiber

Brakes:

Front Brake: Shimano BR-R8170, 2-piston, Hydraulic disc brake
Front Brake Rotor: Shimano RT-MT800, 160 mm, Center lock
Rear Brake: Shimano BR-R8170, 2-piston, Hydraulic disc brake
Rear Brake Rotor: Shimano RT-MT800, 140 mm, Center lock

Derailleurs:

Front Derailleur: Shimano Ultegra Di2, FD-R8150, Brazed-On
Rear Derailleur: Shimano Ultegra Di2, RD-R8150 Shadow, 12-Speed

Drivetrain:

Cassette: Shimano CS-R8100, 11-30 T
Chain: Shimano CN-M8100
Crankset: Shimano Ultegra, FC-R8100, 52/36 T

Shift Lever:

Shimano Ultegra Di2, ST-R8170

Wheelset:

Reynolds AR41 DB Custom, Tubeless ready, Center lock, 12x100/12x142 mm

Tire:

Vittoria Rubino Pro IV, 700x25 mm

Handlebar:

43, 47 cm: Devox Carbon 31.8 mm, 380 mm
51 cm: Devox Carbon 31.8 mm, 400 mm
54, 56 cm:Devox Carbon 31.8 mm, 420 mm
58, 61 cm: Devox Carbon 31.8 mm, 440 mm

Stem:

Devox Aluminum Stem,+/ -7 °

Saddle:

Prologo Dimension 143 T4.0

Seat Post:

43, 47, 51 cm: Devox Carbon, 294 mm
54, 56, 58, 61 cm: Devox Carbon, 344 mm

FR Disc series. ISO standards dictate that there should be sufficient clearance of at least 4mm on both sides of a tire that accurately measures 28mm wide when full inflated. Based on these standards, we cannot therefore recommend any tire that measures wider than 28mm. Different rim and tire combinations will produce varying widths, due to discrepancies and differences among manufacturers, models, inner rim widths and other factors.

This bike comes partially assembled, about 80%, with a difficulty level of 5/10. Some of the tasks required include connecting and installing the Di2 battery, making brake and shift adjustments, installing the front wheel and rotor, and assembling the handlebar with bar tape wrapping. To retain the full warranty from Felt, it is recommended that the bike be assembled by a reputable bike shop. It doesn’t need to be a Felt dealer, just a brick-and-mortar store with experience. Please retain both the build invoice and your proof of purchase from us, as they may be needed if you need to file a warranty claim in the future.

GEOMETRY

	43	47	51	54	56	58	61
(A) Top Tube Length	495 mm	512 mm	530 mm	548 mm	563 mm	583 mm	604 mm
(B) Seat Tube Length	405 mm	425 mm	465 mm	505 mm	525 mm	555 mm	595 mm
(C) Seat Tube Angle	75.25 °	74.5 °	74 °	73.5 °	73.5 °	73.25 °	73 °
(D) Head Tube Length	90 mm	100 mm	115 mm	135 mm	155 mm	177 mm	205 mm
(E) Steering Angle	70.5 °	71.5 °	72.25 °	73 °	73.5 °	73.75 °	74 °
(F) Chain Stay Length	403 mm	403 mm	403 mm	405 mm	405 mm	407 mm	410 mm
(G) Wheel Base	965 mm	967 mm	969 mm	980 mm	986 mm	1003 mm	1021 mm
(H) Standover Height	657 mm	676 mm	710 mm	747 mm	767 mm	790 mm	828 mm
(I) BB-Drop	72 mm	72 mm	72 mm	70 mm	70 mm	70 mm	70 mm
(K) Fork Offset	52 mm	52 mm	47 mm	47 mm	43 mm	43 mm	43 mm
(L) Stack	499 mm	512 mm	530 mm	550 mm	572 mm	594 mm	621 mm
(M) Reach	362 mm	369 mm	377 mm	385 mm	394 mm	405 mm	414 mm
(N) Stem Length	80 mm	80 mm	90 mm	100 mm	100 mm	110 mm	120 mm
(O) Crank Length	165 mm	165 mm	170 mm	172.5 mm	172.5 mm	175 mm	175 mm
